3 Spectrum Analyzer Mode
3.5 ACP Measurement
State Saved Yes
Backwards
Compatibility
SCPI
[:SENSe]:ACPower:OFFSet[1]|2:LIST:BWIDth:VIDeo:AUTO
Filter Type
Selects the type of bandwidth filter that is used.
Remote Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:SHAPe GAUSsian |
FLATtop,…
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:SHAPe?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:LIST:BAND:SHAP FLAT,GAUS,GAUS,GAUS,GAUS,GAUS
:ACP:OFFS2:LIST:BAND:SHAP?
Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are
accepted without error but ignored
Dependencies When "Res BW" on page 936 Mode for the offset is Auto, this cell is grayed out and disabled. Since
Res BW Mode for the offset is preset to Auto on changing "Meas Method" on page 970 to RBW, FAST
or Fast Power, this cell is grayed-out and disabled too. If the cell is pressed, an advisory message is
generated. If the equivalent remote command is sent, a "Setting conflict" warning is generated
Preset When "Max Num of Offsets" on page 1010 is 12, the preset value of Offset G ~ L is GAUSsian
GAUSsian, GAUSsian, GAUSsian, GAUSsian, GAUSsian, GAUSsian
State Saved Saved in instrument state
Range
GAUSsian|FLATtop
Backwards
Compatibility SCPI
[:SENSe]:ACPower:OFFSet[1]|2:LIST:BWIDth:SHAPe
Filter BW
Selects a Gaussian filter based on its –3 dB (Normal) bandwidth or its –6 dB
bandwidth.
Remote Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:TYPE DB3 | DB6,…
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:TYPE?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:LIST:BAND:TYPE DB3,DB3,DB3,DB3,DB3,DB3
:ACP:OFFS2:LIST:BAND:TYPE?
Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are
accepted without error but ignored
Spectrum Analyzer Mode User's &Programmer's Reference 989
