3 Spectrum Analyzer Mode
3.3 Channel Power Measurement
–3 dB (Normal) filter BW Res BW 300 Hz
–6 dB filter BW Res BW (–6 dB) 422 Hz
Noise filter BW Res BW (Noise) 317 Hz
Impulse filter BW Res BW (Impulse) 444 Hz
CISPR filter BW Res BW (CISPR) 200 Hz
MIL filter BW Res BW (MIL) 1 kHz
Flattop filter type Res BW (Flattop) 300 Hz
Backwards
Compatibility
SCPI
[:SENSe]:CHPower:BWIDth:SHAPe
3.3.5 Display
Lets you configure display items for the current Mode, Measurement View or
Window.
3.3.5.1 Meas Display
Contains controls for setting up the display for the current Measurement, View or
Window.
Bar Graph On/Off
Turns the Bar Graph On or Off.
Remote Command
:DISPlay:CHPower:WINDow[1]:BGRaph ON | OFF | 1 | 0
:DISPlay:CHPower:WINDow[1]:BGRaph?
Example
:DISP:CHP:WIND:BGR ON
:DISP:CHP:WIND:BGR?
Preset
OFF
State Saved Saved in instrument state
Range
ON|OFF
Backwards Compatibility
SCPI
:DISPlay:CHPower:VIEW[1]:WINDow[1]:BGRaph
3.3.5.2 Annotation
Contains controls for setting up the annotation for the current Mode or
Measurement.
Spectrum Analyzer Mode User's &Programmer's Reference 613
