Keysight x-series User Manual

6 Input/Output
6.10 Calibrator Control
6.10 Calibrator Control
Lets you select a calibrator and control the calibrator settings.
6.10.1 Select Cal Source
Lets you select the calibrator to control.
Remote Command
:SYSTem:CALibration:TUNE[:SELected] NONE | REF50 | REF4800 | TUNAble |
CALOUT | RCM1 | RCM2 | RCM3 | RCM4 | RCM5 | RCM6 | RCM7 | RCM8 | RCM9 |
RCM10
:SYSTem:CALibration:TUNE[:SELected]?
Example
:SYST:CAL:TUNE:SEL TUNABLE
:SYST:CAL:TUNE?
Notes Options are:
NONE
No calibrator selected
TUNAble
Tunable internal calibrator present in N9042B
CALOUT
Tunable calibrator available through CALOUT front panel port in N9042B
REF50
50 MHz calibrator
REF4800
4.8 GHz calibrator
RCM1 – RCM10
RCal module
Dependencies If the selected calibrator is not available, it does not appear in the dropdown. If you send SCPI to
select a calibrator that is not available, the instrument generates an error
Couplings Selecting REF50 sets the RF Calibrator to REF50
Selecting REF4800 sets the RF Calibrator to REF4800
Selecting a calibrator source other than REF50 or REF4800 sets RF Calibrator to OFF
Preset Unaffected by Mode Preset. Set to NONE by Restore Input/Output Defaults or Restore System
Defaults->All
6.10.2 Cal Output
Lets you set the selected calibrator’s RF power output state.
Remote
Command
:SYSTem:CALibration:TUNE:OUTput[:STATe] ON | OFF | 1 | 0
:SYSTem:CALibration:TUNE:OUTput[:STATe]?
Example
:SYST:CAL:TUNE:OUTP ON
:SYST:CAL:TUNE:OUTP?
2520 Spectrum Analyzer Mode User's &Programmer's Reference
