Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.4 Occupied BW Measurement
–
If averaging/hold is on, averaging/hold starts over
–
Auto Sweep Points is set to OFF (5GNR Mode only)
The resolution of setting the sweep time depends on the number of points selected
Preset
Mode Value
MSR, LTEAFDD, LTEATDD 2001
5GNR Automatically calculated
All Others 1001
State Saved Saved in instrument state
Min 101
Max 20001
Annotation On second line of annotations, in lower right corner in parenthesis behind the sweep annotation
IF Dithering
Lets you turn IF Dithering on or off. This is a technique used in unpreselected
instruments (such as Keysight’s modular instruments) to enhance the rejection of
images and internally-generated spurious signals.
Remote Command
[:SENSe]:SWEep:IF:DITHer OFF | ON | 0 | 1
[:SENSe]:SWEep:IF:DITHer?
Dependencies Only appears in Spectrum Analyzer Mode in VXT models
Preset
OFF
State Saved Saved in instrument state
Image Protection
Lets you turn IF Protection on or off. This is a technique used in unpreselected
instruments (such as Keysight’s modular instruments) to detect and suppress
images and spurs that may be present in non-preselected hardware.
IF Protection takes two sweeps and by correlating the data between them, provides
a single, correct power-versus-frequency trace.
Remote Command
[:SENSe]:SWEep:IMAGeprot OFF | ON | 0 | 1
[:SENSe]:SWEep:IMAGeprot?
Dependencies Only appears in Spectrum Analyzer Mode in VXT models
Preset
ON
State Saved Saved in instrument state
842 Spectrum Analyzer Mode User's &Programmer's Reference
