Keysight x-series User Manual

5 Preset
5.8 User Preset All Modes
5.8 User Preset All Modes
Recalls all the User Preset files for each Mode, switches to the Power-on Mode, and
activates the saved measurement from the Power-on Mode User Preset file.
User Preset All Modes can be executed from the "Preset Dropdown" on page 2206
See also "User Preset" on page 2212.
Remote
Command
:SYSTem:PRESet:USER:ALL
Example
:SYST:PRES:USER:SAVE
:SYST:PRES:USER:ALL
Notes :SYST:PRES:USER:SAVE is used to save the current state as the user preset state
Status Bits/OPC
dependencies
Clears all pending OPC bits. The Status Byte is set to 0
Spectrum Analyzer Mode User's &Programmer's Reference 2215

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
