3 Spectrum Analyzer Mode
3.10 TOI Measurement
Span:3dB RBW
Selects the ratio between span and resolution bandwidth.
Normally, Span:3dB RBW (Auto) selects a Span:3 dB RBW ratio of 106:1. If you
manually enter the ratio, the toggle on Span:3dB RBW changes to Man. This
enables you to manually select ratios more suitable for certain measurements.
When Span:3dB RBW is manually selected, it may be returned to the coupled state
by setting the toggle on RBW:3 dB RBW back to Auto. This may also be done by
pressing "Auto Couple" on page 2017 or by performing a Preset.
Remote
Command
[:SENSe]:TOI:FREQuency:SPAN:BANDwidth[:RESolution]:RATio <integer>
[:SENSe]:TOI:FREQuency:SPAN:BANDwidth[:RESolution]:RATio?
Example
:TOI:FREQ:SPAN:BAND:RAT 106
Notes The values shown in this table reflect the conditions after a Mode Preset
Preset 106
State Saved Saved in instrument state
Min 2
Max 10000
Auto Function
Remote
Command
[:SENSe]:TOI:FREQuency:SPAN:BANDwidth[:RESolution]:RATio:AUTO OFF | ON | 0 |
1
[:SENSe]:TOI:FREQuency:SPAN:BANDwidth[:RESolution]:RATio:AUTO?
Example
:TOI:FREQ:SPAN:BAND:RAT:AUTO 0
Backwards
Compatibility
SCPI
[:SENSe]:TOI:FREQuency:SPAN:BWIDth[:RESolution]:RATio
3.10.5 Display
Opens the Display Menu, which lets you configure display items for the current
Mode, Measurement View or Window.
3.10.5.1 Annotation
Contains controls for setting up the annotation for the current Mode or
Measurement.
Spectrum Analyzer Mode User's &Programmer's Reference 1809
