3 Spectrum Analyzer Mode
3.2 Swept SA Measurement
+30dBm. For example, the reference level value range can be initially set to values
from –170 dBm to 30dBm with no Reference Level Offset. If the reference level is
first set to –20dBm, then Reference Level Offset can be set to values of –150 to
+50dB.
If Reference Level Offset is first set to –30dB, then the reference level can be set to
values of –200dBm to 0dBm. In this case, Reference Level is “clamped” at 0dBm
because the maximum limit of +30dBm is reached with a reference level setting of
0dBm with an offset of –30dB. If instead, Reference Level Offset is first set to 30dB,
then Reference Level can be set to values of –140 to +60dBm.
Number of Divisions
Lets you set the number of divisions vertically in the graticule. For example, set this
to 12 to allow 120dB of dynamic range with a scale of 10 dB/division.
Remote
Command
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:NDIVision 6 | 8 | 10 | 12 | 16 | 20
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:NDIVision?
Example
:DISP:WIND:TRAC:Y:NDIV 12
Preset 10
State Saved Saved in instrument state
3.2.3.2 Attenuation
Controls the attenuator functions and interactions between the attenuation system
components.
There are two attenuator configurations in the X-Series. One is a Dual-Attenuator
configuration consisting of a mechanical attenuator and an optional electronic
attenuator. The other configuration uses a single attenuator with combined
mechanical and electronic sections that controls all the attenuation functions.
Different models in the X-Series come with different configurations.
–
See "Dual-Attenuator Configurations" on page 213
–
See "Single-Attenuator Configuration" on page 213
Most attenuation settings are the same for all measurements – they do not change
as you change measurements. Settings like these are called “Meas Global” and are
unaffected by Meas Preset.
Only available when the hardware set includes an input attenuator, which is typically
only the case for Keysight’s benchtop instruments. For example, this tab does not
appear in VXT models M9420A/10A/11A/15A/16A, M9410E/11E/15E/16E, nor in
UXM. In UXM, all Attenuation and Range settings are disabled, as the expected
212 Spectrum Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
