3 Spectrum Analyzer Mode

3.2 Swept SA Measurement

Remote Command

:CALCulate:MARKer[1]|2|…|24[:SET]:DTRAce

Example Move the Display Trace to Marker 2’s trace in the Waterfall window:

:CALC:MARK2:DTRA

Notes Sending this command selects the subopcoded marker

If the specified marker is Off, this command simply turns it on at the center of the screen, on the

current Display Trace in the Waterfall window

Dependencies Only appears when the Waterfall window is visible

Move Marker -> Display Trace

Moves the Marker in the Waterfall window to the current Display Trace.

Remote Command

:CALCulate:MARKer[1]|2|…|24[:SET]:MTRAce

Example Move Marker 2 to the Display Trace in the Waterfall window:

:CALC:MARK2:MTRA

Notes Sending this command selects the subopcoded marker

If the specified marker is Off, this command simply turns it on at the center of the screen, on the

current Display Trace in the Waterfall window

Dependencies Only appears when the Waterfall window is visible

3.2.7.8 Counter

Accesses Marker Counter controls. Does not appear in certain instruments, such as

VXT.

Marker Count

Turns the marker frequency counter on or off. The selected marker is counted, and if

the selected marker is a Delta marker and its reference marker is not Fixed, the

reference marker is counted as well.

See:

–

"Understanding the Marker Counter" on page 377

–

"Query Count Value (Remote Query Only)" on page 377

Remote Command

:CALCulate:MARKer[1]|2|…|24:FCOunt[:STATe] OFF | ON | 0 | 1

:CALCulate:MARKer[1]|2|…|24:FCOunt[:STATe]?

Example Select Marker 2, turn it on, and turn on the counter:

:CALC:MARK2:FCO ON

Spectrum Analyzer Mode User's &Programmer's Reference 375
