3 Spectrum Analyzer Mode
3.8 Spurious Emissions Measurement
Notes <alphanumeric> is case insensitive; you can specify mixed case, however the name will be
evaluated on a single case
If <alphanumeric> name already exists as a View, the error message “-224, Illegal parameter value;
View
<alphanumeric>
already
exists”
is
generated
If the display is disabled (via :DISP:ENAB OFF) then the error message “-221, Settings conflict; User
View SCPI cannot be used while Display is disabled” is generated
Re-Save User View
You can re-edit a User View; if you make changes, then an asterisk will appear next
to the User View’s name. You can then tap Re-Save User View to save it back to its
existing name, or Save Layout as New View to add another, new User View.
This is a front panel function only, there is no remote command available to perform
this function. To do this remotely, you must first perform Save Layout as New View,
then delete the old User View and rename the new one with the name of the View
you just deleted.
Rename User View
You can rename the current View by giving it a new unique name. Only User Views
can be renamed, if the current View is a Predefined View, an error occurs.
Remote
Command
:DISPlay:VIEW:ADVanced:REName
<alphanumeric>
Example
:DISP:VIEW:ADV:REN “Baseband”
Notes <alphanumeric> is case insensitive; you can specify mixed case, however the name will be
evaluated on a single case
If the <alphanumeric> specifying the new name is already present in the list of View names, the
error
message
“-224,
Illegal
parameter
value;
View
<alphanumeric>
already
exists”
is
generated
If the current View is a Predefined View, the error message “-224, Illegal parameter value; Cannot
rename a Predefined View” is generated
If the display is disabled (via :DISP:ENAB OFF) then the error message “-221, Settings conflict;
View SCPI cannot be used while Display is disabled” is generated
Delete User View
You can delete the current View if it is a User View. The default view becomes the
current view for the Measurement.
Remote
Command
:DISPlay:VIEW:ADVanced:DELete
Spectrum Analyzer Mode User's &Programmer's Reference 1413
