Keysight x-series User Manual

2 User Interface
2.18 Multiscreen
–
Each Screen has a tab that contains the name of the Mode and Measurement in
the box and a number associated with the instance of that Mode. You can enter
a custom Screen name that replaces the Mode name, by going into the
Mode/Meas dialog
–
There is always one and only one selected Screen. It is indicated by a blue tab.
Only the selected Screen is actually running a measurement and updating its
display
–
The selected window in the selected screen is the context for the current menus.
It is the only window on the display with a blue border
–
As you go from screen to screen, each screen remembers the last menu that was
active in that screen and restores it as the active menu
In Multiscreen View, as in Single Screen View, tapping the blue tab or pressing the
Mode/Meas front panel key opens the "Mode/Meas/View Dialog" on page 88 which
allows you to change the Mode (or Measurement or View) being displayed in that
Screen.
Remote
Command
:INSTrument:SCReen:MULTiple[:STATe] OFF | ON | 0 | 1
:INSTrument:SCReen:MULTiple?
Example
:INST:SCR:MULT ON
Notes If only one screen is configured, attempting to set Multi-Screen ON generates the error “-221, Settings
conflict; Multi-Screen requires >1 screen”
Preset OFF
For more information, see the following:
–
"Select Screen" on page 178
–
"Screen List (Remote only command)" on page 179
2.18.1 Select Screen
You can select a screen by touching its tab or, in "Multiscreen" on page 176 mode,
touching the screen itself. Selecting the Screen activates the screen and suspends
the previously selected screen (if any).
Remote
Command
:INSTrument:SCReen:SELect <screen name>
:INSTrument:SCReen:SELect?
Example
:INST:SCR:SEL “Baseband”
Notes If the <screen name> is specified but not found in the list of Screens, the error message “-224, Illegal
parameter value; Screen Name not found” is generated
If the display is disabled (via :DISP:ENAB OFF) then the error message “-221, Settings conflict;
Screen SCPI cannot be used when Display is disabled” is generated
Spectrum Analyzer Mode User's &Programmer's Reference 178

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
