7 Save/Recall/Print

7.2 Recall

Remote Command

:MMEMory:LOAD:RTYPe ALL | ANALyzer | SOURce

Example

:MMEM:LOAD:RTYP ALL

Dependencies Only available in models with a built-in source, such as VXT models

Preset

ALL

Range

ALL|ANALyzer|SOURce

7.2.2.2 Register 1 thru Register 16

Selecting any one of these register buttons causes the State to be recalled from the

specified Register. The registers are provided for rapid saving and recalling, since

you do not need to specify a filename or navigate to a file. Each of the register menu

keys annotates whether it is empty or at what date and time it was last modified. In

addition, you can edit any of the register names to enter custom names for any

Although these 16 registers are the only registers available from the front panel,

there are 128 state registers available in the instrument. Registers 17-128 are only

available from the SCPI interface, using the *RCL command.

There is one set of 128 state registers in the instrument, not one set for each Mode.

When a state is saved, the Mode it was saved from is saved with it; then when it is

recalled, the instrument switches to that Mode.

NOTE

In products that run multiple simultaneous instances of the X-Series Application,

all instances share the same registers and file directories, so make sure you

know from what instance a file or register was saved before recalling it.

The date displayed follows the format specified in the Date Format setting in the

Control Panel. The time shows hours and minutes.

After the recall completes, the message "Register <register number> recalled" is

displayed.

If you are in the Spectrum Analyzer Mode, and you are recalling a register that was

saved in the Spectrum Analyzer Mode, then after the recall, you will still be in the

Recall Register menu. If the Recall causes you to switch modes, then after the

Recall, you will be in the Frequency menu.

If a requested register is empty an error is generated.

Example

*RCL 1

Range 1-16 from front panel, 1-128 from SCPI

Spectrum Analyzer Mode User's &Programmer's Reference 2534
