Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.10 TOI Measurement
Notes Forces a measurement restart
Preset
OFF
Range
ON|OFF
Zero-Span RBW
Zero-Span RBW is the resolution bandwidth used when making the zero-span
intermod measurements when "Zero-Span Measurement" on page 1831 is ON. The
Zero-Span RBW is typically smaller than the main resolution bandwidth, although it
must still be large enough to accommodate three times the width of the
intermodulation products.
The required frequency accuracy of the lower and upper base frequencies increases
when Zero-Span RBW decreases. For this reason, frequency counting is used when
the lower and upper base frequencies are in auto mode. For optimum measurement
speed, set the lower and upper base frequencies explicitly.
Remote
Command
[:SENSe]:TOI:ZSPan:BANDwidth|BWIDth <frequency>
[:SENSe]:TOI:ZSPan:BANDwidth|BWIDth?
Example
:TOI:ZSP:BAND 300 kHz
Notes Forces a measurement restart
Couplings When Auto is on, Zero-Span RBW is one step down from the measurement RBW
Preset 3 MHz
Min 1 Hz
Max 8 MHz
Auto Function
Remote
Command
[:SENSe]:TOI:ZSPan:BANDwidth|BWIDth:AUTO OFF | ON | 0 | 1
[:SENSe]:TOI:ZSPan:BANDwidth|BWIDth:AUTO?
Example
:TOI:ZSP:BAND:AUTO ON
Preset
ON
Dwell Time
This is the sweep time used when making the zero-span intermod measurements
when "Zero-Span Measurement" on page 1831 is ON. Additional sweep time gives
better noise performance.
Remote
Command
[:SENSe]:TOI:ZSPan:SWEep:TIME <time>
[:SENSe]:TOI:ZSPan:SWEep:TIME?
Example
:TOI:ZSP:SWE:TIME 66.24 ms
1832 Spectrum Analyzer Mode User's &Programmer's Reference
