3 Spectrum Analyzer Mode
3.8 Spurious Emissions Measurement
3.8.1.2 All Ranges
Windows: "Graph" on page 1355,
Select All Ranges to view measurement results for all the ranges.
–
The upper window displays a merged trace of all the ranges
–
The lower window displays a list of spurs detected in a measurement cycle. The
currently selected spur, which is highlighted, can be changed by the Spur
control in the Meas Setup menu
Example
:DISP:SPUR:VIEW ALL
3.8.2 Windows
The following windows are available in this measurement:
1.
"Graph" on page 1355
2.
"Table" on page 1356
3.
"All Range Table" on page 1357
4.
"Gate" on page 1358
5.
"Marker Table" on page 1358
The Gate Window is available only when "Gate View On/Off" on page 2686 is ON in
Gate Settings under Trigger.
3.8.2.1 Graph
Window #1 & #3
Appears in several Views, as follows:
View Size Position
Graph + Metrics Three fifth, full width Top
All Ranges Three fifth, full width Top
Gate View One third, full width Middle
When Graph + Metrics is selected
Spectrum Analyzer Mode User's &Programmer's Reference 1355
