6 Input/Output
6.7 Output
The output is off during an alignment but not during a marker count, and is not
blanked during retrace (after a sweep and before the next sweep starts).
6.7.8 Arbitrary IF Freq
Sets the frequency of the Arbitrary IF when "Aux IF Out" on page 2468 is set to AIF.
NOTE
In instruments with Options B2X or B5X, the Arbitrary IF Output is only practical
when the IF Bandwidth is <= 40 MHz, IF Path is <= 40 MHz, or FFT Width is <=
40 MHz.
Remote Command
:OUTPut:AUX:AIF <value>
:OUTPut:AUX:AIF?
Example
:OUTP:AUX:AIF 50 MHZ
Dependencies Only appears if "Aux IF Out" on page 2468 is AIF
Preset Unaffected by a Preset, but set to 70 MHz by Restore Input/Output Defaults or Restore System
Defaults->All
State Saved Saved in Input/Output State
Min 10 MHz
Max 75 MHz
6.7.9 Ext/Wide IF Out
Causes the signal that is normally routed to the IF to be routed instead to the Ext IF
Out connector on the rear panel (N9041B) or Wide IF Out connector on the front
panel (N9042B) or rear panel (N9032B). This is available in N9041B when RF Input 2
is the selected input port and in N9032B/N9042B on RF Input and, when V3050A is
attached, External RF Input.
Only one IF output (Ext/Wide IF Out, IF2 Out, or Aux IF Out) can be selected at a
time, so switching Ext/Wide IF Out to ON changes IF2 Out and Aux IF Out to OFF, and
setting Aux IF Out to something other than OFF or IF2 Out to ON forces Ext/Wide IF
Out to OFF.
Remote Command
:OUTPut:EIF ON | OFF | 1 | 0
:OUTPut:EIF?
Example
:OUTP:EIF ON
Dependencies Only appears in N9041B, N9032B, and N9042B
For N9041B, enabled when RF Input 2 is the selected input. When RF Input 2 is not selected, the
control is grayed out and forced to Off and attempting to set it On will result in an error message
2470 Spectrum Analyzer Mode User's &Programmer's Reference
