3 Spectrum Analyzer Mode
3.9 SEM Measurement
the Offset F value
WLAN Mode: See table of "WLAN Mode Presets" on page 1636 below
State Saved Saved in instrument state
Min/Max 100 Hz/Depends on instrument maximum frequency. Same as the Max Span in Swept SA Measurement
WLAN Mode Presets
Radio Std Presets
802.11a/g
(OFDM/DSSS-OFDM)
802.11n (20MHz)
11 MHz, 20 MHz, 30 MHz, 40 MHz, 100 MHz, 250 MHz, 250 MHz, 250
MHz, 250 MHz, 250 MHz, 250 MHz, 250 MHz, 250 MHz, 250 MHz
802.11b/g
(DSSS/CCK/PBCC)
22 MHz, 50 MHz, 70 MHz, 90 MHz, 100 MHz, 120 MHz, 120 MHz, 120
MHz, 120 MHz, 120 MHz, 120 MHz, 120 MHz, 120 MHz, 120 MHz
802.11n (20MHz) 11 MHz, 20 MHz, 30 MHz, 40 MHz, 100 MHz, 200 MHz, 200 MHz, 200
MHz, 200 MHz, 200 MHz, 200 MHz, 200 MHz, 200 MHz, 200 MHz
802.11n (40MHz) 21 MHz, 40 MHz, 60 MHz, 70 MHz, 100 MHz, 200 MHz, 300 MHz, 300
MHz, 300 MHz, 300 MHz, 300 MHz, 300 MHz, 300 MHz, 300 MHz
802.11ac (20MHz) 11 MHz, 20 MHz, 30 MHz, 40 MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz, 50
MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz
802.11ac (40MHz) 21 MHz, 40 MHz, 60 MHz, 70 MHz, 100 MHz, 100 MHz, 100 MHz, 100
MHz, 100 MHz, 100 MHz, 100 MHz, 100 MHz, 100 MHz, 100 MHz
802.11ac (80MHz) 41 MHz, 80 MHz, 120 MHz, 125 MHz, 200 MHz, 200 MHz, 200 MHz, 200
MHz, 200 MHz, 200 MHz, 200 MHz, 200 MHz, 200 MHz, 200 MHz
802.11ac (160MHz) 81 MHz, 160 MHz, 240 MHz, 250 MHz, 400 MHz, 400 MHz, 400 MHz, 400
MHz, 400 MHz, 400 MHz, 400 MHz, 400 MHz, 400 MHz, 400 MHz
802.11ac (80 MHz +
80MHz)
100Hz, 40 MHz, 79 MHz, 81 MHz, 161 MHz, 200 MHz, 240 MHz, 250 MHz,
250 MHz, 250 MHz, 250 MHz, 250 MHz, 250 MHz, 250 MHz
802.11ah (1MHz) 0.6MHz, 1 MHz, 1.5 MHz, 2.5MHz, 2.5 MHz, 2.5 MHz, 2.5 MHz, 2.5 MHz,
2.5 MHz, 2.5 MHz, 2.5 MHz, 2.5 MHz, 2.5 MHz, 2.5 MHz
802.11ah (2MHz) 1.1 MHz, 2 MHz, 3 MHz, 5MHz, 5 MHz, 5 MHz, 5 MHz, 5 MHz, 5 MHz, 5
MHz, 5 MHz, 5 MHz, 5 MHz, 5 MHz
802.11ah (4MHz) 2.1 MHz, 4 MHz, 6 MHz, 10 MHz, 10 MHz, 10 MHz, 10 MHz, 10 MHz, 10
MHz, 10 MHz, 10 MHz, 10 MHz, 10 MHz, 10 MHz
802.11ah (8MHz) 4.1 MHz, 8 MHz, 12 MHz, 20 MHz, 20 MHz, 20 MHz, 20 MHz, 20 MHz, 20
MHz, 20 MHz, 20 MHz, 20 MHz, 20 MHz, 20 MHz
802.11ah (16MHz) 8.1 MHz, 16 MHz, 24 MHz, 40 MHz, 40 MHz, 40 MHz, 40 MHz, 40 MHz, 40
MHz, 40 MHz, 40 MHz, 40 MHz, 40 MHz, 40 MHz
802.11j/p (20MHz) 10MHz, 11 MHz, 20 MHz, 30 MHz, 50MHz, 50 MHz, 50 MHz, 50 MHz, 50
MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz
802.11j/p (10MHz) 5MHz, 5.5 MHz, 10 MHz, 15 MHz, 25MHz, 250MHz, 250MHz, 250MHz,
250 MHz, 250MHz, 250MHz, 250MHz, 250MHz, 250MHz
1636 Spectrum Analyzer Mode User's &Programmer's Reference
