Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.6 Power Stat CCDF Measurement
Input 2, CXA and MXE
Model CF after Mode Preset Stop Freq after Mode Preset Max Freq
(can't tune above)
CXA opt C75 0.7505 GHz 1.5 GHz 1.58 GHz
MXE 505 MHz 1GHz 1.000025 GHz
Tracking Generator Frequency Limits (CXA only)
Tracking
Generator
Option
Min Freq
(clips to this freq when turn
TG on and can’t tune below
while TG on)
If above this Freq, Stop Freq
clipped to this Freq when TG
turned on
Max Freq
(can't tune
above)
while TG on
T03 9 kHz 3.0 GHz 3.08 GHz
T06 9 kHz 6.0GHz 6.05 GHz
Tracking Generator Frequency Limits(CXA-m only)
Tracking
Generator
Option
Min Freq
(clips to this freq when turn
TG on and can’t tune below
while TG on)
If above this Freq, Stop Freq
clipped to this Freq when TG
turned on
Max Freq
(can't tune
above)
while TG on
T03 2 MHz 3.08 GHz 3.08 GHz
T07 2 MHz 7.575 GHz 7.575 GHz
T13 2 MHz 13.8 GHz 13.8 GHz
T26 2 MHz 26.55 GHz 26.55 GHz
VXT Models with Radio Heads/CIU Frequency Range
The following table shows the Center Frequency Presets and Range for VXT modes
with Radio Heads/CIU.
Products with Radio Heads/CIU Preset Start frequency Stop frequency
M9421A + CIU 6 GHz 5.9 GHz 12 GHz
M9410A + CIU 6 GHz 5.9 GHz 12 GHz
M9410A + CIU + RRH 25 GHz 24.25 GHz 43.5 GHz
RF Center Freq
Lets you specify the RF Center Frequency. Sets the Center Frequency to use when
the RF input is selected, even if the RF input is not selected at the time the
command is sent. Note that Center Frequency in the Frequency menu on the front
panel always applies to the currently selected input.
Remote Command
[:SENSe]:FREQuency:RF:CENTer <freq>
1196 Spectrum Analyzer Mode User's &Programmer's Reference
