Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.7 Burst Power Measurement
Input CF after Mode Preset Stop Freq after Mode Preset Max Freq
(can't tune above)
Input 2, opt 585 42.505 GHz 85.0 GHz 86 GHz
Input 2, opt 590 45.005 GHz 90.0 GHz 92 GHz
Input 2, opt 5CX 55.005 GHz 110.0 GHz 110 GHz
Input 2, CXA and MXE
Model CF after Mode Preset Stop Freq after Mode Preset Max Freq
(can't tune above)
CXA opt C75 0.7505 GHz 1.5 GHz 1.58 GHz
MXE 505 MHz 1GHz 1.000025 GHz
Tracking Generator Frequency Limits (CXA only)
Tracking
Generator
Option
Min Freq
(clips to this freq when turn
TG on and can’t tune below
while TG on)
If above this Freq, Stop Freq
clipped to this Freq when TG
turned on
Max Freq
(can't tune
above)
while TG on
T03 9 kHz 3.0 GHz 3.08 GHz
T06 9 kHz 6.0GHz 6.05 GHz
Tracking Generator Frequency Limits(CXA-m only)
Tracking
Generator
Option
Min Freq
(clips to this freq when turn
TG on and can’t tune below
while TG on)
If above this Freq, Stop Freq
clipped to this Freq when TG
turned on
Max Freq
(can't tune
above)
while TG on
T03 2 MHz 3.08 GHz 3.08 GHz
T07 2 MHz 7.575 GHz 7.575 GHz
T13 2 MHz 13.8 GHz 13.8 GHz
T26 2 MHz 26.55 GHz 26.55 GHz
RF Center Freq
Specifies the RF Center Frequency. Sets the Center Frequency to be used when the
RF input is selected, even if the RF input is not the input that is selected at the time
the command is sent. Note that Center Frequency in the Frequency menu on the
front panel always applies to the currently selected input.
Remote Command
[:SENSe]:FREQuency:RF:CENTer <freq>
[:SENSe]:FREQuency:RF:CENTer?
Example
:FREQ:RF:CENT 30 MHz
:FREQ:RF:CENT?
Spectrum Analyzer Mode User's &Programmer's Reference 1305
