Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.8 Spurious Emissions Measurement
Freq Option CF after Mode
Preset
Stop Freq after Mode
Preset
Max Freq
(can't tune
above)
526 (except CXA and
MXE)
13.255 GHz 26.5 GHz 27.0 GHz*
526 (CXA) 13.255 GHz 26.5GHz 26.55 GHz
526 (MXE) 1.805 GHz 3.6GHz 27.0 GHz
532 16.005 GHz 32.0GHz 32.5 GHz
540 20.005 GHz 40.0GHz 40.5GHz
543 21.505 GHz 43.0 GHz 43.0 GHz
544 22.005 GHz 44.0 GHz 45.0 GHz
550 25.005 GHz 50.0 GHz 52 GHz
F03 (CXA-m) 1.505 GHz 3.0 GHz 3.08 GHz
F07 (CXA-m) 3.755 GHz 7.5GHz 7.575 GHz
F13 (CXA-m) 6.805 GHz 13.6GHz 13.8 GHz
F26 (CXA-m) 13.255 GHz 26.5GHz 26.55 GHz
504 (M9421A, M8920A) 2.145 GHz 3.88GHz 3.88 GHz
506 (M9421A, M8920A) 3.245 GHz 6.08GHz 6.08 GHz
F06 (M9410A/11A) 1.0 GHz
6.08 GHz 6.08 GHz
F06 (M9415A)
1 GHz 1.08 GHz
6.6 GHz
F08 (M9415A)
1 GHz 1.08 GHz
8.6 GHz
F12 (M9415A)
1 GHz 1.08 GHz
12.9 GHz
*For option 526, the Max CF in RTSA is 26.999999995 GHz.
N9041B Center Freq Presets
Input CF after Mode Preset Stop Freq after Mode Preset Max Freq
(can't tune above)
Input 1, all models 25.005 GHz 50.0 GHz 52 GHz
Input 2, opt 585 42.505 GHz 85.0 GHz 86 GHz
Input 2, opt 590 45.005 GHz 90.0 GHz 92 GHz
Input 2, opt 5CX 55.005 GHz 110.0 GHz 110 GHz
Input 2, CXA and MXE
Model CF after Mode Preset Stop Freq after Mode Preset Max Freq
(can't tune above)
CXA opt C75 0.7505 GHz 1.5 GHz 1.58 GHz
MXE 505 MHz 1GHz 1.000025 GHz
Tracking Generator Frequency Limits (CXA only)
1442 Spectrum Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
