6 Input/Output
6.2 Input
Couplings Connecting a V3050A changes the Preset to ERFIN and automatically switches the input to ERFIN.
Disconnecting the V3050A changes the Preset back to RFIN and automatically switches the input to
RFIN
Preset ERFIN when V3050A is connected, otherwise RFIN
Annotation Annotation in the Meas Bar reads as follows:
–
When input is RFIN: Input: RF
–
When input is RFIN2: Input: RF2
–
When input is ERFIN: Input: Ext RF
Parameters for EXT, EXF and EXM Wireless Test Sets
<port> Input
RFIO1
RFIO 1
RFIO2
RFIO 2
RFIO3
RF3 I|O
RFIO4
RF4 I|O
See also "Parameters for VXT M9410A/11A/15A/16A and EXM when used with
Radio Heads/CIU" on page 2345
Example Set the RF input to RFIO 1:
:FEED:RF:PORT RFIO1
Dependencies In EXF, or in EXM with hardware M9430A, if RF Input is selected as RF Input Port, you need to choose
the settings in the Half Duplex Config menu to determine which port (RFIO3 or RFIO4) will be used
In EXM with hardware M9431A, this setting is not supported. If the SCPI command is sent with this
setting, an error is generated, -221, “Settings conflict; option not installed”
Preset
RFIO1
Annotation Annotation in the Meas Bar reads as follows:
–
When input is RFIO1: Input: RFIO1
–
When input is RFIO2: Input: RFIO2
–
When input is RFIO3: Input: RFIO3
–
When input is RFIO4: Input: RFIO4
Parameters for VXT M9410A/11A/15A16A, M9410E/11E/15E/16E and
M9420A Vector Transceivers
<port> Input
RFIN
RF Input
Spectrum Analyzer Mode User's &Programmer's Reference 2343
