3 Spectrum Analyzer Mode
3.3 Channel Power Measurement
In some PowerSuite measurements, in the LTE-Advanced (both FDD and TDD) and
5G NR modes, when Res BW is in Auto, the resolution bandwidth is predefined
based on the corresponding bandwidth of the single carrier, as shown in the table
below. In the Multi-carrier case, the narrowest RBW among the active carriers is
used.
LTE-A FDD/TDD Modes
Carrier BW Auto RBW, kHz
1.4 MHz 20
3 MHz 43
5 MHz 68
10 MHz 150
15 MHz 220
20 MHz 270
200 kHz (NB-IoT in FDD) 10
5G NR Mode
Bandwidth Auto RBW, kHz
5 MHz 68
10 MHz 150
15 MHz 220
20 MHz 270
25 MHz 360
30 MHz 430
35 MHz 510
40 MHz 560
45 MHz 620
50 MHz 680
60 MHz 820
70 MHz 1000
80 MHz 1100
90 MHz 1300
100 MHz 1500
200 MHz 2700
400 MHz 3000
800 MHz 3000
1600 MHz 3000
2000 MHz 3000
610 Spectrum Analyzer Mode User's &Programmer's Reference
