Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.4 Occupied BW Measurement
Query always returns IS97D
IBW 1.23 MHz
Span 1.845 MHz
RBW 24kHz
VBW Auto rules
Band Class (IS-97D/98D only)
The following function is only available when you have selected the standard: IS-
97D/98D. It lets you select the band class.
Remote
Command
[:SENSe]:RADio:STANdard:BAND:CLASs BC0 | BC1
[:SENSe]:RADio:STANdard:BAND:CLASs?
Example
:RAD:STAN:BAND:CLAS BC0
:RAD:STAN:BAND:CLAS?
Preset
BC0
State Saved Saved in instrument state
Range 0 (800 MHz Band)|1 (1900 MHz Band)
Wireless Radio Standards
The table below lists the CHP settings and provides an example for each wireless
Radio Standard.
WLAN 802.11a Command Example :RAD:STAN WL802DOT11A
IBW 20 MHz
Span 30 MHz
RBW 100 kHz
VBW Auto rules
WLAN 802.11g Command Example :RAD:STAN WL802DOT11G
IBW 20 MHz
Span 30 MHz
RBW 100 kHz
VBW Auto rules
WLAN 802.11b Command Example :RAD:STAN WL802DOT11B
IBW 25 MHz
Span 37.5 MHz
RBW 100 kHz
VBW Auto rules
Spectrum Analyzer Mode User's &Programmer's Reference 813

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
