3 Spectrum Analyzer Mode
3.5 ACP Measurement
RTOCenter
5G NR Mode only
From either the lower or upper RF BW** edge frequency to the center frequency of each Offset Integ
BW
RTOEdge
5G NR Mode only
From either the lower or upper RF BW** edge frequency to the closest edge frequency of each Offset
Integ BW
RCTOCenter
5G NR Mode only
From the center frequency of RF BW** to the center frequency of each Offset Integ BW
SCTOCenter
5G NR Mode only
From the center frequency of sub-block** to the center frequency of each Offset Integ BW
** RF BW = BWchannel,CA
which is defined in each 3GPP standard, regardless of
“Measure Carrier” for the uppermost and the lowermost carriers being Enabled or
Disabled. When the Number of Component Carrier = 1, RF BW = BW
channel
= 2 x
F
offset,RAT
** sub-block (bandwidth) = BW
channel,block
which is defined in each 3GPP standard,
regardless of “Measure Carrier” for the uppermost and the lowermost carriers being
Enabled or Disabled. When the Number of Component Carrier within each sub-
block = 1, sub-block (bandwidth) = BW
channel
= 2 x F
offset,RAT
.
See "Diagrams for Offset Freq Define" on page 979.
Modes other than MSR, LTEAFDD, LTEATDD, 5G NR
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE CTOCenter | CTOEdge | ETOCenter |
ETOEdge
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:TYPE ETOC
:ACP:OFFS:TYPE?
Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are
accepted without error but ignored
Preset
CTOCenter
State Saved Saved in instrument state
Range
CTOCenter|CTOEdge|ETOCenter|ETOEdge
Mode: MSR, LTEAFDD, LTEATDD
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE CTOCenter | CTOEdge | ETOCenter |
ETOEdge
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE?
978 Spectrum Analyzer Mode User's &Programmer's Reference
