Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.9 SEM Measurement
Mode Values
SA -30.00 dB, -30.00 dB,-30.00 dB, -30.00 dB, -30.00 dB, -30.00 dB
WCDMA -30.00 dB, -30.00 dB, -30.00 dB, -30.00 dB, -30.00 dB, -30.00 dB|-33.73 dB, -
34.00 dB, -37.50 dB, -47.50 dB, -47.50 dB, -47.50 dB
When the max number of offsets is 12 in these modes, the preset value of Offset G ~ L is the same as
the Offset F value
Mode Values
LTEAFDD,
LTEATDD, 5G
NR, MSR
0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB|0 dB, 0
dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB, 0 dB
When the max number of offsets is 14 in these modes, the preset value of Offset G ~ N is the same as
the Offset F value
WLAN Mode: See table of "WLAN Mode Presets" on page 1656 below
State Saved Saved in instrument state
Min/Max -200 dB/50 dB
WLAN Mode Presets
802.11a/g
(OFDM/DSSS-OFDM)
0 dB, -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -47.00 dB, -47.00 dB, -
47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00
dB
802.11b/g
(DSSS/CCK/PBCC)
-30 dB, -50 dB, -50 dB, -50 dB, -50 dB, -50 dB, -50 dB, -50 dB, -50 dB, -
50 dB, -50 dB, -50 dB, -50 dB, -50 dB
802.11n
(20MHz/40MHz)
0 dB, -20.00 dB, -28.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -
45.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -45.00 dB, -45.00
dB
802.11ac/ax/be (20
MHz/ 40 MHz/ 80
MHz/ 160 MHz)
0 dB, -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB
802.11ac/ax (80 MHz +
80 MHz)
-40dB, -40.00 dB, -28.00 dB, -20 dB, 0 dB, - 20 dB, -28 dB, -40 dB, -40
dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB
802.11ah (1 MHz/ 2
MHz/ 4 MHz/ 8 MHz/
16 MHz)
0 dB, -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB
802.11j/p 20M, j/p
10M, p5M
0 dB, -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB
802.11af (6MHz/
7MHz/ 8MHz)
0 dB, -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB
1656 Spectrum Analyzer Mode User's &Programmer's Reference
