Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.9 SEM Measurement
[:SENSe]:SEMask:BANDwidth[1]|2:INTegration?
Example
:SEM:BAND:INT 10 MHz
:SEM:BAND:INT?
Notes 10% . 100% of Channel Span Parameter Value
Bandwidth sub op code, 1 is for BTS, 2 for MS. Default is BTS
Note that Bandwidth sub op code 2 is supported only in non-SA Modes. In SA Mode, Bandwidth sub
op code 1 is used for both BTS and MS
If the ref channel is outside the frequency range, the result spectrum will be invalid
Dependencies Not shown in MSR, LTE-Advanced FDD/TDD and 5G NR Modes
In order to maintain backwards compatible with legacy LTE FDD/TDD Modes, the remote command is
supported in LTE & LTE-A converged application
Couplings Cannot be higher than the channel Span. If lower than 1/10 of channel Span, then the channel Span is
reduced to be 10 times the Integ BW
Preset
Mode Value
SA
3.84MHz
WCDMA
3.84MHz|3.84MHz
WLAN
See the table of "WLAN Mode Presets" on page 1688 below
State Saved Saved in instrument state
Min/Max 1 kHz/Depends on instrument maximum frequency
Backwards
Compatibility SCPI
[:SENSe]:SEMask:BWIDth[1]|2:INTegration
WLAN Mode Presets
Radio Std Presets
802.11a/g (OFDM/DSSS-OFDM)
802.11n/ac (20 MHz)
18 MHz
802.11b/g (DSSS/CCK/PBCC) 22 MHz
802.11n (40MHz)/ 802.11ac (40 MHz) 38 MHz
802.11ac (80 MHz) 78 MHz
802.11ac (160 MHz) 158 MHz
802.11ac (80 MHz + 80 MHz) 78 MHz
802.11ah (1 MHz) 0.9 MHz
802.11ah (2 MHz) 1.8 MHz
802.11ah (4 MHz) 3.8 MHz
802.11ah (8 MHz) 7.8 MHz
1688 Spectrum Analyzer Mode User's &Programmer's Reference
