Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.9 SEM Measurement
For WLAN 802.11ac (80 + 80 MHz), the channel span is coupled with the difference between the
center frequencies of the two carriers. When the difference is either less than 80 MHz, or greater than
565 MHz, a “setting conflict” error message is displayed
Chan Span = Carrier Spacing + Chan IntegBW
When the state of Span is Auto, the span value is automatically determined by multi-carrier config-
uration. Otherwise, the span value depends on user input
When the span value is set manually, the state of span is automatically changes to Man
This key is enabled and can be changed only in single carrier. The span state is always Auto in Multi-
carriers
Preset
Mode Value
SA
5.0MHz
WCDMA
5.0MHz|5.0MHz
LTEAFDD, LTEATDD
5MHz
5GNR
Automatically calculated
WLAN
See the table of "WLAN Mode Presets" on page 1690 below
ON
State Saved Saved in instrument state
Yes
Range Auto|Man
Min/Max 1 kHz/Depends on instrument maximum frequency
WLAN Mode Presets
Radio Std Presets
802.11a/g (OFDM/DSSS-OFDM)
802.11n/ac (20 MHz)
18 MHz
802.11b/g (DSSS/CCK/PBCC) 22 MHz
802.11n/ac (40 MHz) 38 MHz
802.11ac (80 MHz) 78 MHz
802.11ac (160 MHz) 158 MHz
802.11ac (80 MHz + 80 MHz) 320 MHz
802.11ah (1 MHz) 0.9 MHz
802.11ah (2 MHz) 1.8 MHz
802.11ah (4 MHz) 3.8 MHz
802.11ah (8 MHz) 7.8 MHz
802.11ah (16 MHz) 15.8 MHz
802.11j/p (20 MHz) 18 MHz
1690 Spectrum Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
