Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.13 Phase and Amplitude vs Time Measurement
Notes Preset and Max values are dependent on Hardware Options (5xx), port selections or other aspects of
the particular instrument in use
If no terminator (e.g., MHz) is sent, the terminator Hz is used. If a terminator with unit other than
Frequency is used, an invalid suffix error message is generated
Couplings For E7760A, if the Input Port selected is a mmWave port, and option RF4 is not present, the frequency
of the instrument and source must be the same. Thus, changing this instrument frequency will also
update the source frequency. If option RF4 is present, the frequency of the instrument and source are
independent
Preset Depends on instrument’s maximum frequency, mode, measurement, and selected input
See "Center Frequency Presets" on page 2007 , "RF Center Freq" on page 2009, "Ext Mix Center Freq"
on page 2010, and "I/Q Center Freq" on page 2010
State Saved Saved in instrument state
Min Depends on instrument’s maximum frequency, mode, measurement, and selected input
See "Center Frequency Presets" on page 2007 , "RF Center Freq" on page 2009, "Ext Mix Center Freq"
on page 2010, and "I/Q Center Freq" on page 2010
Max Depends on instrument maximum frequency, mode, measurement, and selected input
See "Center Frequency Presets" on page 2007 , "RF Center Freq" on page 2009, "Ext Mix Center Freq"
on page 2010, and "I/Q Center Freq" on page 2010
Status Bits/OPC
dependencies
Non-overlapped
Center Frequency Presets
The following table provides the Center Frequency Presets for the Spectrum
Analyzer mode, and the Max Freq, for the various frequency options:
Freq Option CF after Mode
Preset
Stop Freq after Mode
Preset
Max Freq
(can't tune
above)
503 (all but CXA) 1.805 GHz 3.6 GHz 3.7 GHz
503 (CXA) 1.505 GHz 3.0 GHz 3.08 GHz
507 (all but CXA) 3.505 GHz 7.0GHz 7.1 GHz
507 (CXA) 3.755 GHz 7.5GHz 7.58 GHz
508 (all but MXE) 1.805 GHz 3.6GHz 8.5 GHz
508 (MXE) 4.205 GHz 8.4GHz 8.5 GHz
513 6.805 GHz 13.6GHz 13.8 GHz
526 (except CXA and
MXE)
13.255 GHz 26.5 GHz 27.0 GHz*
526 (CXA) 13.255 GHz 26.5GHz 26.55 GHz
526 (MXE) 1.805 GHz 3.6GHz 27.0 GHz
532 16.005 GHz 32.0GHz 32.5 GHz
Spectrum Analyzer Mode User's &Programmer's Reference 2007

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
