ADSP-21368 SHARC Processor Hardware Reference 4-35
Digital Audio/Digital Peripheral Interfaces
Table 4-6. Group C Sources—Frame Sync
Selection Code Source Signal Description (Source)
00000 (0x0) DAI_PB01_O Select DAI pin buffer 1
00001 (0x1) DAI_PB02_O Select DAI pin buffer 2
00010 (0x2) DAI_PB03_O Select DAI pin buffer 3
00011 (0x3) DAI_PB04_O Select DAI pin buffer 4
00100 (0x4) DAI_PB05_O Select DAI pin buffer 5
00101 (0x5) DAI_PB06_O Select DAI pin buffer 6
00110 (0x6) DAI_PB07_O Select DAI pin buffer 7
00111 (0x7) DAI_PB08_O Select DAI pin buffer 8
01000 (0x8) DAI_PB09_O Select DAI pin buffer 9
01001 (0x9) DAI_PB10_O Select DAI pin buffer 10
01010 (0xA) DAI_PB11_O Select DAI pin buffer 11
01011 (0xB) DAI_PB12_O Select DAI pin buffer 12
01100 (0xC) DAI_PB13_O Select DAI pin buffer 13
01101 (0xD) DAI_PB14_O Select DAI pin buffer 14
01110 (0xE) DAI_PB15_O Select DAI pin buffer 15
01111 (0xF) DAI_PB16_O Select DAI pin buffer 16
10000 (0x10) DAI_PB17_O Select DAI pin buffer 17
10001 (0x11) DAI_PB18_O Select DAI pin buffer 18
10010 (0x12) DAI_PB19_O Select DAI pin buffer 19
10011 (0x13) DAI_PB20_O Select DAI pin buffer 20
10100 (0x14) SPORT0_FS_O Select SPORT 0 frame sync
10101 (0x15) SPORT1_FS_O Select SPORT 1 frame sync
10110 (0x16) SPORT2_FS_O Select SPORT 2 frame sync
10111 (0x17) SPORT3_FS_O Select SPORT 3 frame sync
