ADSP-21368 SHARC Processor Hardware Reference 9-7
S/PDIF Transmitter/Receiver
A set of three preambles, shown in Table 9-1, are used. These preambles
are transmitted in the time allocated to four time slots at the start of each
subframe (time slots 0 to 3) and are represented by eight successive states.
The first state of the preamble is always different from the second state of
the previous symbol (representing the parity bit).
Like bi-phase code, the preambles are dc free and provide clock recovery.
They differ in at least two states from any valid bi-phase sequence.
S/PDIF Transmitter
The S/PDIF transmitter resides within the DAI, and its inputs and out-
puts can be routed through the signal routing unit (SRU1). It receives
audio data in serial format, encloses the specified user status information,
and converts it into the bi-phase encoded signal. The serial data input to
the transmitter can be formatted as left-justified, I
2
S, or right-justified
with word widths of 16, 18, 20 or 24 bits.
The serial data, clock, external sync signal, and frame sync inputs to the
S/PDIF transmitter are routed through SRU1. They can come from a
variety of sources such as the SPORTs, external pins, the precision clock
generators (PCG), or the sample rate converters (SRC). The signal routing
is selected in the SRU1 control registers. For more information, see
“DAI/SRU1 Connection Groups” on page 4-18.
Table 9-1. Preambles
Preamble Preceding state 0 Preceding state 1 Description
X 11100010 00011101 Subframe 1
Y 11100100 00011011 Subframe 2
Z 11101000 00010111 Subframe 1 and
block start
To Next Page
