ADSP-21368 SHARC Processor Hardware Reference A-91
Register Reference
User Bits Buffer Registers for Subframe B
Registers (DITUSRBITBx)
There are six user bits buffer registers associated with subframe B (right
channel). These registers are listed with their locations in Table A-37.
Table A-37. DITUSRBITBx Registers
Register (Address) Bits 7–0 Bits 15–8 Bits 23–16 Bits 31–24
DITUSRBITB0 (0x24E8) BYTE0 BYTE1 BYTE2 BYTE3
DITUSRBITB1 (0x24E9) BYTE4 BYTE5 BYTE6 BYTE7
DITUSRBITB2 (0x24EA) BYTE8 BYTE9 BYTE10 BYTE11
DITUSRBITB3 (0x24EB) BYTE12 BYTE13 BYTE14 BYTE15
DITUSRBITB4 (0x24EC) BYTE16 BYTE17 BYTE18 BYTE19
DITUSRBITB5 (0x24ED) BYTE20 BYTE21 BYTE22 BYTE23
