Sony/Philips Digital Interface Registers
A-90 ADSP-21368 SHARC Processor Hardware Reference
Right Channel Status for Subframe B
Registers (DITCHANBx)
There are six channel status buffer registers associated with subframe B.
These registers are listed with their locations in Table A-35.
User Bits Buffer Registers for Subframe A
Registers (DITUSRBITAx)
There are six user bits buffer registers associated with subframe A (left
channel). These registers are listed with their locations in Table A-36.
Table A-35. DITCHANBx Registers
Register (Address) Bits 7–0 Bits 15–8 Bits 23–16 Bits 31–24
DITCHANB0 (0x24A2) BYTE1 BYTE2 BYTE3 BYTE4
DITCHANB1 (0x24DA) BYTE5 BYTE6 BYTE7 BYTE8
DITCHANB2 (0x24DB) BYTE9 BYTE10 BYTE11 BYTE12
DITCHANB3 (0x24DC) BYTE13 BYTE14 BYTE15 BYTE16
DITCHANB4 (0x24DD) BYTE17 BYTE18 BYTE19 BYTE20
DITCHANB5 (0x24DE) BYTE21 BYTE22 BYTE23 Reserved
Table A-36. DITUSRBITAx Registers
Register (Address) Bits 7–0 Bits 15–8 Bits 23–16 Bits 31–24
DITUSRBITA0 (0x24E0) BYTE0 BYTE1 BYTE2 BYTE3
DITUSRBITA1 (0x24E1) BYTE4 BYTE5 BYTE6 BYTE7
DITUSRBITA2 (0x24E2) BYTE8 BYTE9 BYTE10 BYTE11
DITUSRBITA3 (0x24E3) BYTE12 BYTE13 BYTE14 BYTE15
DITUSRBITA4 (0x24E4) BYTE16 BYTE17 BYTE18 BYTE19
DITUSRBITA5 (0x24E5) BYTE20 BYTE21 BYTE22 BYTE23
