Making Connections in the SRUs
4-30 ADSP-21368 SHARC Processor Hardware Reference
011000 (0x18) SPORT2_DA_O Select SPORT 2A data
011001 (0x19) SPORT2_DB_O Select SPORT 2B data
011010 (0x1A) SPORT3_DA_O Select SPORT 3A data
011011 (0x1B) SPORT3_DB_O Select SPORT 3B data
011100 (0x1C) SPORT4_DA_O Select SPORT 4A data
011101 (0x1D) SPORT4_DB_O Select SPORT 4B data
011110 (0x1E) SPORT5_DA_O Select SPORT 5A data
011111 (0x1F) SPORT5_DB_O Select SPORT 5B data
100000 (0x20) SRC0_DAT_OP_O SRC0 data out (stereo)
100001 (0x21) SRC1_DAT_OP_O SRC1 data out (stereo)
100010 (0x22) SRC2_DAT_OP_O SRC2 data out (stereo)
100011 (0x23) SRC3_DAT_OP_O SRC3 data out (stereo)
100100 (0x24) SRC0_TDM_IP_O SRC0 data out
100101 (0x25) SRC1_TDM_IP_O SRC1 data out
100110 (0x26) SRC2_TDM_IP_O SRC2 data out
100111 (0x27) SRC3_TDM_IP_O SRC3 data out
101000 (0x28) DIR_DAT_O SPDIF_RX serial data out
101001 (0x29) LOW Select logic level low (0)
101010 (0x2A) LOW Select logic level low (0)
101011 (0x2B) HIGH Select logic level high (1)
101100 (0x2C) SPORT6_DA_O Select SPORT 6A data
101101 (0x2D) SPORT6_DB_O Select SPORT 6B data
101110 (0x2E) SPORT7_DA_O Select SPORT 7A data
101111 (0x2F) SPORT7_DB_O Select SPORT 7B data
Table 4-5. Group B Sources—Serial Data (Cont’d)
Selection Code Source Signal Description (Source)
