ADSP-21368 SHARC Processor Hardware Reference 4-29
Digital Audio/Digital Peripheral Interfaces
Table 4-5. Group B Sources—Serial Data
Selection Code Source Signal Description (Source)
000000 (0x0) DAI_PB01_O Select DAI pin buffer 1
000001 (0x1) DAI_PB02_O Select DAI pin buffer 2
000010 (0x2) DAI_PB03_O Select DAI pin buffer 3
000011 (0x3) DAI_PB04_O Select DAI pin buffer 4
000100 (0x4) DAI_PB05_O Select DAI pin buffer 5
000101 (0x5) DAI_PB06_O Select DAI pin buffer 6
000110 (0x6) DAI_PB07_O Select DAI pin buffer 7
000111 (0x7) DAI_PB08_O Select DAI pin buffer 8
001000 (0x8) DAI_PB09_O Select DAI pin buffer 9
001001 (0x9) DAI_PB10_O Select DAI pin buffer 10
001010 (0xA) DAI_PB11_O Select DAI pin buffer 11
001011 (0xB) DAI_PB12_O Select DAI pin buffer 12
001100 (0xC) DAI_PB13_O Select DAI pin buffer 13
001101 (0xD) DAI_PB14_O Select DAI pin buffer 14
001110 (0xE) DAI_PB15_O Select DAI pin buffer 15
001111 (0xF) DAI_PB16_O Select DAI pin buffer 16
010000 (0x10) DAI_PB17_O Select DAI pin buffer 17
010001 (0x11) DAI_PB18_O Select DAI pin buffer 18
010010 (0x12) DAI_PB19_O Select DAI pin buffer 19
010011 (0x13) DAI_PB20_O Select DAI pin buffer 20
010100 (0x14) SPORT0_DA_O Select SPORT 0A data
010101 (0x15) SPORT0_DB_O Select SPORT 0B data
010110 (0x16) SPORT1_DA_O Select SPORT 1A data
010111 (0x17) SPORT1_DB_O Select SPORT 1B data
