ADSP-21368 SHARC Processor Hardware Reference 4-59
Digital Audio/Digital Peripheral Interfaces
011011 27 SPI_FLG3_O Slave select 3 from SPI
011100 28 SPIB_MISO_O MISO from SPIB
011101 29 SPIB_M0SI_O MOSI from SPIB
011110 30 SPIB_CLK_O Clock output from SPIB
011111 31 SPIB_FLG0_O Slave select 0 from SPIB
100000 32 SPIB_FLG1_O Slave select 1 from SPIB
100001 33 SPIB_FLG2_O Slave select 2 from SPIB
100010 34 SPIB_FLG3_O Slave select 3 from SPIB
100011 35 FLAG4_O Flag 4 output
100100 36 FLAG5_O Flag 5 output
100101 37 FLAG6_O Flag 6 output
100110 38 FLAG7_O Flag 7 output
100111 39 FLAG8_O Flag 8 output
101000 40 FLAG9_O Flag 9 output
101001 41 FLAG10_O Flag 10 output
101010 42 FLAG11_O Flag 11 output
101011 43 FLAG12_O Flag 12 output
101100 44 FLAG13_O Flag 13 output
101101 45 FLAG14_O Flag 14 output
101110 46 FLAG15_O Flag 15 output
101111 47 PCG_CLKC_O Precision clock generator clock C out
110000 48 PCG_CLKD_O Precision clock generator clock D out
110001 49 PCG_FSC_O Precision clock generator frame sync C out
Table 4-12. Group B Signals (Cont’d)
Binary Decimal Signal Description
