Making Connections in the SRUs
4-58 ADSP-21368 SHARC Processor Hardware Reference
000011 03 DPI_P02_O External pin 2
000100 04 DPI_P03_O External pin 3
000101 05 DPI_P04_O External pin 4
000110 06 DPI_P05_O External pin 5
000111 07 DPI_P06_O External pin 6
001000 08 DPI_P07_O External pin 7
001001 09 DPI_P08_O External pin 8
001010 10 DPI_P09_O External pin 9
001011 11 DPI_P10_O External pin 10
001100 12 DPI_P11_O External pin 11
001101 13 DPI_P12_O External pin 12
001110 14 DPI_P13_O External pin 13
001111 15 DPI_P14_O External pin 14
010000 16 TIMER0_O Timer0 output
010001 17 TIMER1_O Timer1 output
010010 18 TIMER2_O Timer2 output
010011 19 UART0_TX_O UART0 transmitter output
010100 20 UART1_TX_O UART1 transmitter output
010101 21 SPI_MISO_O MISO from SPI
010110 22 SP_IM0SI_O MOSI from SPI
010111 23 SPI_CLK_O Clock output from SPI
011000 24 SPI_FLG0_O Slave select 0 from SPI
011001 25 SPI_FLG1_O Slave select 1 from SPI
011010 26 SPI_FLG2_O Slave select 2 from SPI
Table 4-12. Group B Signals (Cont’d)
Binary Decimal Signal Description
