Sample Rate Converter Registers
A-106 ADSP-21368 SHARC Processor Hardware Reference
23–22 SRC3_DEEMPHASIS De-emphasis Filter Select. Enables de-emphasis on
incoming audio data for SRC 3.
00 = No de-emphasis
01 = 33 kHz
10 = 44.1 kHz
11 = 48 kHz
24 SRC3_SOFTMUTE Soft Mute. Enables soft mute on SRC 3.
0 = No mute
1 = Mute (default)
25 SRC3_DITHER Dither Select. Disables dithering on SRC 3 when a word
length less than 24 bits is selected.
0 = Dithering is disabled (default)
1 = Dithering is enabled
27–26 SRC3_SMODEOUT Serial Output Format. Selects the serial output format
for SRC 3 as follows:
00 = Left-justified (default)
01 = I
2
S
10 = TDM mode
11 = Right-justified
29–28 SRC3_LENOUT Output Word Length Select. Selects the serial output
word length for SRC 3 as follows:
00 = 24 bits
01 = 20 bits
10 = 18 bits
11 = 16 bits
Any word length less than 24 bits will have dither added
to the unused LSBs if SRCx_DITHER is enabled (= 1).
30 SRC3_MPHASE Match-Phase Mode Select. Configures the SRC 3 mod-
ules to not use their own internally-generated sample rate
ratio but use an externally-generated ratio. Used with
TDM data.
0 = Matched-phase disabled (default)
1 = Matched-phase enabled
31 SRC3_ENABLE SRC Enable. Enables SRC 3.
0 = Disabled
1 = Enabled
Table A-43. SRCCTL1 Register Bit Descriptions (Cont’d)
Bit Name Description
