ADSP-21368 SHARC Processor Hardware Reference 7-13

Input Data Port

Figure 7-14. Hold Timing for Four 8-Bit Words to 32 Bits (Mode 00)

PDAP_CLK

PDAP_DAT[19:12]

PDAP_HOLD

B0A0 C0 D0 A1 B1

PDAP_CLK

PDAP_DAT[19:12]

PDAP_HOLD

B0A0 C0 D0
