January 2007
2-77
WorkCentre 7132
005-147, 005-150
Status-indicator-raps
Revision
Check the wire between J765 and J755 for an open circuit or a short circuit (BSD 5.5 Flag
2).
The wire between J765 and J755 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P755-1 (+) and GND (-), and between
P755-6 (+) and GND (-) (BSD 5.5 Flag 2).
The voltage is approx. +24VDC.
YN
Replace the DADF PWB (PL 16.3).
Replace the DADF Registration Motor (PL 16.9) If the problem persists, replace the
DADF PWB (PL 15.3).
Execute Component Control [005-072]. The Exit Nip Release Solenoid can be heard.
YN
Check the connections of P/J766 and P/J756. P/J766 and P/J756 are connected cor-
rectly.
YN
Connect P/J766 and P/J756.
Check the wire between P756 and J766 for an open circuit or a short circuit (BSD 5.6 Flag
2).
The wire between P756 and J766 is conducting without an open circuit or a
short circuit.
YN
Repair the open circuit or short circuit.
Replace the Exit Nip Release Solenoid (PL 16.4) If the problem persists, replace the
DADF PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
005-150 CVT Holed Paper Feed Sensor Off Jam
BSD-ON:5.4
Feed Sensor does not turn Off in specified time from Feed Sensor On in holed document
mode.
Procedure
Ensure that a point on circumference (farthest from trail edge), not a center, of a hole on trail
edge side is 19mm or less from trail edge.
A B
To Next Page
