Xerox WorkCentre 7132

January 2007
2-730
WorkCentre 7132
093-960, 093-961
Revision
Status-indicator-raps
093-960 Toner Y CRUM Data Mismatch Failure
BSD-ON:9.1
Y Toner CRUM Data Mismatch Failure.
Initial Actions
• Ensure a Yellow Toner Cartridge is installed in the Yellow position in the Rotary
• Ensure the correct toner cartridge for this product is installed
• Ensure that the Yellow Toner Cartridge is seated correctly.
• Ensure that the Toner Cartridge Door is closed.
Procedure
Fault codes 093-926 (K), 093-961 (M), and 093-962 (C) are also present on the UI.
YN
Replace the Yellow Toner Cartridge (PL 5.2).
Replace the Toner CRUM (Toner Cartridge Door) (PL 5.1).
If the fault codes are still present, replace the MCU PWB (PL 11.1).
093-961 Toner M CRUM Data Mismatch Failure
BSD-ON:9.1
M Toner CRUM Data Mismatch Failure.
Initial Actions
• Ensure a Magenta Toner Cartridge is installed in the Magenta position in the Rotary
• Ensure the correct toner cartridge for this product is installed
• Ensure that the Magenta Toner Cartridge is seated correctly.
• Ensure that the Toner Cartridge Door is closed.
Procedure
Fault codes 093-926 (K), 093-960 (Y), and 093-962 (C) are also present on the UI.
YN
Replace the Magenta Toner Cartridge (PL 5.2).
Replace the Toner CRUM (Toner Cartridge Door) (PL 5.1).
If the fault codes are still present, replace the MCU PWB (PL 11.1).
