January 2007
3-33
WorkCentre 7132
M, C, K Banding Defect
Image Quality
Reversion 4.0
M, C, K Banding Defect
Figure 1 M, C, K Banding Defect Sample (VA-006)
Cause
This defect is caused by one of several components:
• Developer Assembly
•IBT Assembly
• Fuser Assembly
• ROS Assembly
Corrective Action
.Replace the above components in order, one at a time.
