012-161 Finisher Set Eject Jam RAP
BSD-ON:12.4/12.7
After the Eject Motor turned On, the Compile Paper Sensor (PL 16.9did not turn Off within the
specified time.
Initial Actions
• Power Off/On
Procedure
Execute Component Control [012-151 Compile Paper Sensor]. Actuate the Compile Paper
Sensor with paper.
The display changes.
YN
Check the connections of P/J8806 and P/J8848. P/J8806 and P/J8848 are con-
nected correctly.
YN
Connect P/J8806 and P/J8848.
Check the wire between J8806 and J8848 for an open circuit or a short circuit (BSD 12.4
Flag 3/Flag 4).
The wire between J8806 and J8848 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8848-A6 (+) and GND (-) (BSD 12.4
Flag 4).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 17.12).
Measure the voltage between the Finisher PWB P8848-A5 (+) and GND (-) (BSD 12.4
Flag 3).Actuate the Compile Paper Sensor with paper.
The voltage changes.
YN
Replace the Compile Paper Sensor (PL 17.9).
Replace the Finisher PWB (PL 17.12).
Alternately execute Component Control [012-081 Eject Motor FORWARD ON] and Component
Control [012-082 Eject Motor REVERSE ON].
The Eject Motor starts up.
YN
Check the connections of P/J8801 and P/J8846. P/J8801 and P/J8846 are con-
nected correctly.
YN
Connect P/J8801 and P/J8846.
Check the wire between J8801 and J8846 for an open circuit or a short circuit (BSD 12.7
Flag 5).
The wire between J8801 and J8846 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the resistance of the Eject Motor between J8801-2/5 (COM) and each point of
J8801-1/3/4/6 (BSD 12.7 Flag 5).
The resistance is approx. 2Ohm.
YN
Replace the Eject Motor (PL 17.7).
Measure the voltage between the Finisher PWB P8846-6 (+) and GND (-), and between
P8846-12 (+) and GND (-) (BSD 12.7 Flag 5).
The voltage is approx. +24VDC.
YN
Replace the Finisher PWB (PL 17.12).
Replace the Eject Motor (PL 17.7). If the problem persists, replace the Finisher PWB (PL
17.12).
Replace the Finisher PWB (PL 17.12).
