January 2007
2-159
WorkCentre 7132
012-317, 012-318
Status-indicator-raps
Revision
012-317 Stapler Feed Ready Failure RAP
BSD-ON:12.6
The Staple Head did not feed the staple wire to the Staple Ready Sensor in a specific time.
Initial Actions
• Power Off/On
Procedure
Execute Component Control [012-043 Staple Ready Sensor]. Select [012-046 Staple Motor].
The Stapler Motor can be heard.
YN
Check the connections of P/J8819 and P/J8847. P/J8819 and P/J8847 are con-
nected correctly.
YN
Connect P/J8819 and P/J8847.
Check the wire between J8819 and J8847 for an open circuit or a short circuit (BSD 12.6
Flag 1).
The wire between J8819 and J8847 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Staple Assembly (PL 17.8). If the problem persists, replace the Finisher PWB
(PL 17.12).
Execute Component Control [012-243 Staple Ready Sensor].
Alternately execute Component Control [012-046 Staple Motor FORWARD ON] and Compo-
nent Control [012-047 Staple Motor REVERSE ON]. The display changes.
YN
Check the connections of P/J8818 and P/J8852. P/J8818 and P/J8852 are con-
nected correctly.
YN
Connect P/J8818 and P/J8852.
Check the wire between J8818 and J8852 for an open circuit or a short circuit (BSD 12.6
Flag 2/Flag 3).
The wire between J8818 and J8852 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8852-1 (+) and P8852-5 (-) (BSD 12.6
Flag 2).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 17.12).
Replace the Staple Assembly (PL 17.8). If the problem persists, replace the Finisher PWB
(PL 17.12).
Replace the Finisher PWB (PL 17.12).
012-318 Set Clamp Home Sensor On Failure RAP
BSD-ON:12.7
After the Set Clamp started operation, the Set Clamp Home Sensor did not turn On within
200ms.
Initial Actions
• Power Off/On
• Remove foreign substances in the Eject Clamp mechanism.
Procedure
Manually operate the Eject Clamp mechanism. The Eject Clamp mechanism moves
smoothly.
YN
Replace the parts that are interfering with operation.
Execute Component Control [012-251 Set Clamp Home Sensor]. Actuate the Set Clamp
Home Sensor with paper. The display changes.
YN
Check the connections of P/J8802 and P/J8849. P/J8802 and P/J8849 are connected
correctly.
YN
Connect P/J8802 and P/J8849.
Check the wire between J8802 and J8849 for an open circuit or a short circuit (BSD 12.7
Flag 1/Flag 2).
The wire between J8802 and J8849 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8849-9 (+) and GND (-) (BSD 12.7 Flag
2).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 17.12).
Measure the voltage between the Finisher PWB P8849-8 (+) and GND (-) (BSD 12.7 Flag
1).
Actuate the Set Clamp Home Sensor with paper. The voltage changes.
YN
Replace the Set Clamp Home Sensor (PL 17.7).
Replace the Finisher PWB (PL 17.12).
Alternately execute Component Control [012-081 Eject Motor FORWARD ON] and Component
Control [012-082 Eject Motor REVERSE ON].
The Eject Motor starts up.
YN
Check the connections of P/J8801 and P/J8846. P/J8801 and P/J8846 are con-
nected correctly.
YN
Connect P/J8801 and P/J8846.
A B
To Next Page
