6-3
WorkCentre 7132
UI Diagnostic Mode
General procedures information
Reversion 4.0
UI Diagnostic Mode
Procedure
Access UI Diagnostics by following the procedures below.
Entering UI Diagnostics
1. At the Control Panel, press and hold the 0 key for 5 seconds, then press the Start button
while still pressing the 0 key.
The CE Mode - Password Entry screen will appear.
2. Enter the Access Number 6789 and press Confirm.
The colors on the display are reversed to indicate that UI Diagnostics mode is active.
Accessing Diagnostic routines
1. Press the Log In/Out button on the Control Panel.
2. Select System Settings.
3. Select Common Settings.
4. Select Maintenance/Diagnostics.
5. The following Diagnostics Routines can be accessed from the UI screen. (Figure 1)
a. NVM Read/Write
– Follow the instructions on the screen. If one or more NVM locations is changed,
the machine will reboot upon exit.
b. Component Control
c. Sub System
– Initialize Hard Disk
– Delete All Data
– Software Options
– Fax Diagnostics
d. Print Test Pattern
e. Initialize NVM
f. Adjustment/Others
– Machine ID/Billing Data
– Initialize HFSI Counter
– Adjust Toner Density
– Tray 5(Bypass) Guide Adjustment (Tray 5=MPT)
Figure 1 Maintenance/Diagnostics
aintenance / Diagnostics
NVM Read / Write
IO Check
Sub System
Component Control
Analog Monitor
Size Detection Auto Adjus
Hard Disk Failure
Prediction Test
Fax Diagnostics
Initialize Hard Disk
Blank Page Threshold
Value
Delete All Data
Software Options
Print Test Pattern
Initialize NVM
Procon on/off Print
IIT Calibration
TRC Adjustment
Adjust Toner Density
IOT
Output Device
Faults
Max Setup
IISS
Input Device
Sys-System
Sys-User
Adjustment / Others Machine ID / Billing Data
Tray 5(Bypass) Guide
Adjustment (Tray 5=MPT)
Measure IBT Belt Speed
Initialize HFSI Counter
