January 2007
2-659
WorkCentre 7132
073-211
Status-indicator-raps
Revision
073-211 Tray 3 RAP
BSD-ON:7.4/7.6
The Tray 3 Paper Size Switch failed.
Initial Actions
Ensure the tray is set up and loaded correctly.
Procedure
Remove Tray 3. Check the condition of the Tray 3 Paper Size Switch and actuators. The Tray
3 Paper Size Switch and actuators appear to be free of damage.
YN
Replace the Tray 3 Paper Size Switch (PL 14.1).
Check the Tray 3 actuator on the back of Tray 3. The actuator is good.
YN
Repair as required (PL 14.1)
Go to the OF 2 Size Switch Assy RAP.
To Next Page
