January 2007
2-772
WorkCentre 7132
116-379, 116-380
Revision
Status-indicator-raps
116-379 Controller Software RAP
An internal shutdown occurred after an MCC processing error.
Initial Actions
Power Off/On
Procedure
Reinstall or replace the DIMM (PL 11.2).
If the problem persists reload Software (ADJ 9.3.1).
If the problem persists, replace the ESS PWB (PL 11.2).
116-380 ESS Font ROM DIMM #1 RAP
An error is detected when the Font ROM DIMM #1 was checked.
Initial Actions
Power Off/On
Procedure
Pull out and insert the Printer PWB (PL 11.2) and the PS DIMM (PL 11.2) Switch on the power.
The problem persists.
YN
Return to Service Call Procedures.
Check the connection of each ESS PWB connector. The connectors are correctly con-
nected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the ESS PWB (PL 11.2)
If the problem persists, replace the Printer PWB (PL 11.2)
If the problem persists, replace the PS DIMM (PL 11.2).
