024-917 Stacker Tray Staple Set Over Count RAP
BSD-ON:12.9
The number of stapled copies exceeded the capacity of the Stacker Tray.
Initial Actions
• Power Off/On
Procedure
Check the connection of each Finisher PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Turn on the power again. [024-917] reoccurs.
YN
Return to Service Call Procedures.
Replace the Finisher PWB (PL 17.12) If the problem persists, replace the MCU PWB (PL 11.1).
024-919 Face UP Tray Close RAP
When output was sent to the Face Up Tray, the Face Up Tray was detected as closed.
Initial Actions
Open the Face Up Tray.
Procedure
Check that the P/Js on the MCU PWB (PL 11.1) are securely connected.
