Status-indicator-raps
Measure the voltage between the DADF PWB P759-6 (+) and GND (-) (BSD 5.1 Flag 4).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P759-5 (+) and GND (-) (BSD 5.1 Flag 3).
Actuate the DADF Tray Size 2 Sensor with paper. The voltage changes.
YN
Replace the DADF Tray Size 2 Sensor (PL 16.10).
Replace the DADF PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
005-198 Document Length RAP
BSD-ON:5.4
The system detected a document with a length shorter than 115mm in the Slow Scan Direction.
Initial Actions
• Power Off than On
Procedure
Check the document size. The size of the document is within the specification.
YN
Use a paper size within the specification.
Execute Component Control [005-205]. Actuate the DADF Feed Out Sensor with paper. The
display changes.
YN
Check the connections of P/J769 and P/J758. P/J769 and P/J758 are connected cor-
rectly.
YN
Connect P/J769 and P/J758.
Check the wire between J769 and J758 for an open circuit or a short circuit (BSD 5.4 Flag
13/Flag 14).
The wire between J769 and J758 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P758-3 (+) and GND (-) (BSD 5.4 Flag
14).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P758-2 (+) and GND (-) (BSD 5.4 Flag 13).
Actuate the DADF Feed Out Sensor with paper. The voltage changes.
YN
Replace the DADF Feed Out Sensor (PL 16.9).
Replace the DADF PWB (PL 16.3).
Execute Component Control [005-206]. Actuate the DADF Pre Registration Sensor with paper.
The display changes.
YN
Check the connections of P/J781 and P/J761. P/J781 and P/J761 are connected cor-
rectly.
YN
Connect P/J781 and P/J761.
Check the wire between J781 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
3/Flag 4).
The wire between J781 and J761 is conducting without an open circuit or
a short circuit.
A B
A
