January 2007
4-159
WorkCentre 7132
REP 16.4.2, REP 16.5.1
Repairs/Adjustments
Reversion 4.0
Figure 3 Removing the Rear Cover
REP 16.5.1 Stack Height Sensor Assembly
Parts List on PL 17.5
Removal
WARNING
To avoid personal injury or shock, do not perform repair or adjustment with electrical
power applied to the machine.
CAUTION
Check that “Ready to Copy” is displayed on the Control Panel display.
1. Remove the link from the Top Open Cover Assembly. (Figure 1)
1. Lift up the Top Open Cover Assembly.
2. Remove the screws on both sides.
3. Remove the links on both sides.
Figure 1 Removing the link
2. Remove the Stack Height Sensor Assembly. (Figure 2)
1. Remove the screw.
2. Disconnect the connector.
3. Remove the Stack Height Sensor Assembly.
