Xerox WorkCentre 7132 Service Documentation

January 2007
2-165
WorkCentre 7132
012-905, 012-923
Status-indicator-raps
Revision
012-905 Compile Paper Sensor RAP
BSD-ON:12.4
Paper remains on the Compile Paper Sensor.
Initial Actions
• Remove foreign substances on the sensor.
• Power Off/On
Procedure
Execute Component Control [012-151 Compile Paper Sensor]. Actuate the Compile Paper
Sensor with paper.
The display changes.
YN
Check the connections of P/J8806 and P/J8848. P/J8806 and P/J8848 are con-
nected correctly.
YN
Connect P/J8806 and P/J8848.
Check the wire between J8806 and J8848 for an open circuit or a short circuit (BSD 12.4
Flag 3/Flag 4).
The wire between J8806 and J8848 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8848-A6 (+) and GND (-) (BSD 12.4
Flag 4).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 17.12).
Measure the voltage between the Finisher PWB P8848-A5 (+) and GND (-) (BSD 12.4
Flag 3).
Actuate the Compile Paper Sensor with paper. The voltage changes.
YN
Replace the Compile Paper Sensor (PL 17.9).
Replace the Finisher PWB (PL 17.12).
Replace the Finisher PWB (PL 17.12).
012-923 H-Transport Entrance Sensor B RAP
BSD-ON:12.2
During standby, paper was detected by the H-Transport Entrance Sensor.
Initial Actions
• Remove foreign substances on the sensor.
• Power Off/On
Procedure
Execute Component Control [012-190 H-Transport Entrance Sensor]. Actuate the H-Transport
Entrance Sensor with paper.
The display changes.
YN
Check the connections of P/J8380 and P/J8390. P/J8380 and P/J8390 are con-
nected correctly.
YN
Connect P/J8380 and P/J8390.
Check the wire between J8380 and J8390 for an open circuit or a short circuit (BSD 12.2
Flag 5/Flag 6).
The wire between J8380 and J8390 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8390-12 (+) and GND (-) (BSD 12.2
Flag 6).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 17.12).
Measure the voltage between the Finisher PWB P8390-13 (+) and GND (-) (BSD 12.2
Flag 5).Actuate the H-Transport Entrance Sensor with paper.
The voltage changes.
YN
Replace the H-Transport Entrance Sensor (PL 17.3).
Replace the Finisher PWB (PL 17.12).
Replace the Finisher PWB (PL 17.12).
