Status-indicator-raps
005-915 CVT APS No1 Sensor RAP
BSD-ON:5.4
Paper remains on the APS Sensor 1.
Initial Actions
• Remove the paper.
• Power Off than On
Procedure
Execute Component Control [005-218 DADF APS 1 Sensor]. Actuate the DADF APS 1 Sensor
with paper.
The display changes.
YN
Check the connections of P/J777 and P/J761. P/J777 and P/J761 are connected cor-
rectly.
YN
Connect P/J777 and P/J761.
Check the wire between J777 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
7/Flag 8).
The wire between J777 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-6 (+) and GND (-) (BSD 5.4 Flag 8).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P761-5 (+) and GND (-) (BSD 5.4 Flag 7).
Actuate the DADF APS 1 Sensor with paper. The voltage changes.
YN
Replace the DADF APS 1 Sensor (PL 16.7).
Replace the DADF PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
005-916 CVT APS No2 Sensor RAP
BSD-ON:5.4
Paper remains on the APS Sensor 2.
Initial Actions
• Remove the paper.
• Power Off than On
Procedure
Execute Component Control [005-219 DADF APS 2 Sensor]]. Actuate the DADF APS 2 Sen-
sor with paper. The display changes.
YN
Check the connections of P/J778 and P/J761. P/J778 and P/J761 are connected cor-
rectly.
YN
Connect P/J778 and P/J761.
Check the wire between J778 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
9/Flag 10).
The wire between J778 and J761 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-3 (+) and GND (-) (BSD 5.4 Flag
10).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P761-2 (+) and GND (-) (BSD 5.4 Flag 9).
Actuate the DADF APS 2 Sensor with paper. The voltage changes.
YN
Replace the DADF APS 2 Sensor (PL 16.7).
Replace the DADF PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
