January 2007
2-617
WorkCentre 7132
062-362, 062-371
Status-indicator-raps
Revision
062-362 IIT/IPS PWB RAP
BSD-ON:6.3
Control Logic detected a failure in the IIT/IPS PWB.
Procedure
Switch off the power. Access the IIT/IPS PWB (PL 13.3) Disconnect and reconnect the IIT/IPS
PWB connectors.
If the problem persists reload Software (ADJ 9.3.1).
If the problem persists replace the IIT/IPS PWB (PL 13.3).
062-371 Lamp Illumination RAP
BSD-ON: 6.3
The amount of light from Exposure Lamp is inadequate which gets incident on CCD at the start
of scan or at the initialization of IIT after power on.
Procedure
Check the lamp, lens, mirror and the white correcting plate for abnormalities such as contami-
nation and deterioration. Abnormality such as contamination or deterioration of the lamp,
lens, mirror or the white correcting plate is found.
YN
Replace the lamp, lens, mirror or the white correcting plate.
Execute Component Control [062-002 IIT Exposure Lamp]. The Exposure Lamp lights up.
YN
Check the connections of P/J703, P/J702 and P/J723. P/J703, P/J702 and P/J723
are connected correctly.
YN
Connect P/J703, P/J702 and P/J723.
Check the wire between J702 and J723 for an open circuit or a short circuit. The wire
between J702 and J723 is conducting without an open circuit or a short circuit.
YN
Replace the Lamp Wire Harness (PL 13.6).
Measure the voltage between the IIT/IPS PWB (PL 13.3) P723-1 (+) and GND (-), and
between P723-2 (+) and GND (-) (BSD 6.3 Flag 4).
The voltage is approx. +24VDC.
YN
Replace the IIT/IPS PWB (PL 13.3).
Replace the Exposure Lamp (PL 13.6)
If the problem persists, replace the Lamp Ballast PWB (PL 13.6)
If the problem persists, replace the IIT/IPS PWB (PL 13.3).
Check the connections of P/J700 and P/J710. P/J700 and P/J710 are connected cor-
rectly.
YN
Connect P/J700 and P/J710.
Replace the Lens Kit Assembly (PL 11.4)
If the problem persists, replace the IIT/IPS PWB (PL 13.3).
To Next Page
